Cooler Master MasterBox TD500 Mesh Case - Black

  • Part Number: MCB-D500D-KGNN-S01
  • Manufacturer: Cooler Master
  • Quickfind Code: 105323
  • Stock: Out Stock

Contact for availability

Product Features:
  • Condition: New
  • Form Factor E-ATX
  • RGB / LED Colour RGB
  • Main Colour Black
  • Side Panel Tempered Glass
+ Read More Information

Share:

Product Description

Cooler Master MasterBox TD500 Mesh PC Case | MCB-D500D-KGNN-S01

Design of the E-ATX MasterBox TD500 Mesh adds a new dimension to PC lighting through contour and form, providing custom-built systems a presentation beyond flat, two-dimensional panels. The Crystalline Tempered Glass side panel features a design that interacts with component lighting, precision engineered for both its toughness and its aesthetics through CNC machining.

Polygonal Mesh takes its form from Cooler Master’s Fine Mesh technology—simultaneously providing high airflow, dust filtration, and a strengthened structure. Lighting from the three included ARGB fans respond to the contour of the mesh depending on the viewing angle. Advanced technology is set firmly into fine art as the MasterBox TD500 Mesh carves its own path to the bleeding edge.

Main Features

  • Polygonal Mesh - Crafted from Cooler Master's Fine Mesh technology, Polygonal Mesh features a three-dimensional contour and is also capable of simultaneously providing high airflow and dust filtration.
  • Crystalline Tempered Glass - A crystalline design spans the edges of the tempered glass side panel, precision engineered for strength as well as aesthetics.
  • Triple ARGB Fans - Three addressable RGB fans flood the Polygonal Mesh front panel with lighting while providing considerable airflow to the system. Certified compatible with: ASUS, Gigabyte, MSI and ASRock motherboards.
  • Dual 360mm Radiator Support - For enthusiast-grade cooling, two 360mm radiators are supported on the top and front panel to keep the most extreme systems cool.
  • Versatile Cooling Options - Support for up to seven 120mm fans and 360mm front and top radiator support ensure that performance is not compromised.
  • Room For Upgrades - Support for up to a 410mm graphics card, a 165mm CPU cooler, and up to a 180mm PSU in length provides room for upgrades to stay ahead of the game.
Technical Specification

Cooler Master MasterBox TD500 Mesh Case - Black

Storage

Internal Expansion Bays2 x 2.5"
2 x 2.5"/3.5"

Expansion

Expansion Slots7 x Full Height

Interfaces/Ports

USB Ports2 x USB 3.0
Headphone Ports1 x 3.5mm Jack
Microphone In Port1 x 3.5mm Jack

Electrical

Cooling SystemFront: Supports 3 x 120mm or 2 x 140mm fans (3 x 120mm ARGB fans included)
Top: Supports 3 x 120mm or 2 x 140mm fans
Rear: Supports 1 x 120mm fan
Power SupplyATX Power Supply supported

Physical

Form FactorMid Tower Case
Case ColourBlack
MaterialMesh, Plastic, Steel, Tempered Glass
Motherboard CompatibilityE-ATX
SSI CEB
ATX
MicroATX
Minii-ITX
In The BoxCase
Accesory Box
Width217 mm
Depth493 mm
Height469 mm
Weight6.95 kg

Warranty

Warranty2 Years

Key Features

FirewireNo
Main ColourBlack
Case TypeTower
USB 3.0 SupportYes
Case Form FactorMid Tower
Power Supply IncludedNo
Optimised forGaming
80Plus RatedNo
PSU Form FactorATX
Display Model in ShowroomNo
IlluminatedNo
e-SATANo
L.E.D FanRGB
Internal 3.5" Bay2
Internal 2.5" Bay2
ATXYes
Micro-ATXYes
ITXYes
E-ATXYes
Cooler Height165 mm
Built-in Card ReaderNo
USB Type-C SupportNo
Front HDMINo
Side Panel TypeTempered Glass
GPU Length410 mm
PSU Depth180 mm
Front Audio TypeSeparate
Number of Fans3 fan(s)
LED Controller IncludedYes
LED Strip(s) IncludedNo
Maximum Motherboard Size SupportedE-ATX

Item Details

ManufacturerCooler Master
Manufacturer CodeMCB-D500D-KGNN-S01
EAN4719512095522
ConditionNew
