Well ventilated throughout the entire chassis, the CC560 V2 sports an airflow front panel and a large mesh top panel to ensure fresh air is circulating.
Four pre-installed LED fans deliver big airflow performance, ensuring any system build receives top-notch cooling capacity.
There is enough space to support high-performance AIO liquid coolers, with room for a 360mm radiator in front or 240mm on top. Cooling fan support for up to 8x120mm or 5x140mm fans. The PSU shroud can now support two 120mm fans, providing an extra breath of fresh air to your power-hungry GPU!
With the ability to support up to E-ATX motherboards, 165mm tall CPU coolers, 370mm GPUs, and 170mm PSUs; the CC560 V2 can be configured with a wide range of high end components.
Support for 2x 2.5” SSDs and 2x 3.5” HDDs. One of the HDD bays can be utilized for a third 2.5"" drive if the need arises.
The chassis and side glass panel have been upgraded and reinforced for extra durability, and the magnetic top dust filter makes cleaning a breeze. The 20mm of cable management space behind the motherboard tray provides adequate space to arrange all your wires.
Features an easily accessible USB 3.0 port, a USB 2.0 port, and a combo audio jack.
DeepCool CC560 V2 Mid Tower Gaming Case - Black
Storage
| Internal Expansion Bays | 2 x 2.5" 2 x 3.5" |
Expansion
| Expansion Slots | 7 x Full Height |
Interfaces/Ports
| USB Ports | 1 x USB 3.0 1 x USB 2.0 |
| Headphone Ports | 1 x 3.5mm Jack, shared with Microphone |
Electrical
| Cooling System | Front: Supports 2 x 140mm or 3 x 120mm fans (3 x 120mm Blue LED fans included) Top: Supports 2 x 140mm or 120mm fans Rear: Supports 1 x 120mm fan (Blue LED fan included) PSU Shroud: Supports 2 x 120mm fans |
| Power Supply | ATX Power Supply supported |
Warranty
| Warranty | 1 Year |
Physical
| Form Factor | Mid Tower Case |
| Case Colour | Black |
| Material | ABS SPCC Tempered Glass |
| Motherboard Compatibility | ATX mATX Mini-ITX |
| Width | 215 mm |
| Depth | 432 mm |
| Height | 483 mm |
| Weight | 7.2 kg |
Key Features
| Max Motherboard Width | 244 mm |
| Max Motherboard Height | 305 mm |
| Supports AIO Cooler | Yes |
| Main Colour | Black |
| Case Type | Tower |
| Case Form Factor | Mid Tower |
| Power Supply Included | No |
| Optimised for | Gaming |
| 80Plus Rated | No |
| PSU Form Factor | ATX |
| Illuminated | No |
| L.E.D Fan | Blue |
| Max 3.5" Drives | 2 |
| Max 2.5" Drives | 2 |
| ATX | Yes |
| Micro-ATX | Yes |
| ITX | Yes |
| E-ATX | No |
| Cooler Height | 165 mm |
| Built-in Card Reader | No |
| USB Type-C Support | No |
| Side Panel Type | Tempered Glass |
| GPU Length | 370 mm |
| PSU Depth | 170 mm |
| Number of Fans | 4 fan(s) |
| RGB LED Controller Included | No |
| LED Strip(s) Included | No |
| Maximum Motherboard Size Supported | ATX |
| RGB Software Type | None |
| Total 2.5" + 3.5" drive bays | 4 |
| Power Requirement (auto) | 12 W |
| USB2.0 ports | 1 |
| USB3.0 ports | 1 |
| Low profile expansion | No |
| Vinyl Position - Top | No |
| Vinyl Position - Front | No |
| Vinyl Position - Left | Yes |
| Vinyl Position - Right | Yes |
| Max Supported Radiator Length | 360 mm |
| Create Your Own Gaming PC (CCL) | Yes |
| Back Connect Support | No |
Item Details
| Manufacturer | DeepCool |
| Manufacturer Code | R-CC560-BKGAA4-G-2 |
| Alternative Part Number | R-CC560-BKGAA4-G-1 |
| EAN | 6933412774617 |
