Fractal Design Vector RS Gaming Case - Black

  • Part Number: FD-C-VER1A-01
  • Manufacturer: Fractal Design
  • Quickfind Code: 105540
  • Stock: In Stock

£169.99 ex. vat
£203.99 inc. vat

Product Features:
  • Condition: New
  • Form Factor E-ATX
  • RGB / LED Colour RGB
  • Main Colour Black
  • Side Panel Tempered Glass
+ Read More Information

Share:

Product Description

Command attention

Sharp angles, uncompromising design and a no-nonsense attitude combine to create a case quite unlike any other. Just look at the expressive ARGB strip or the counter-angled air intakes designed to trap noise without restricting airflow, giving you a case that breathes like it’s open – but sounds like it’s closed.

Attractive aesthetics

  • Tinted, bolt-free tempered glass on three sides
  • Top panel easily converts between tempered glass and filtered ventilation
  • Customizable ARGB LED effects wrapping top and front panels in a synchronized span
  • Control via standard 5V RGB motherboard connection or included Adjust R1 controller
  • Compatible with standard 5V RGB motherboard connectors and software
  • Push-to-lock latching for quick side panel access on both sides

Extensive water-cooling support

The Vector RS is designed to offer you a wide range of options for your water-cooling setup.

  • Front radiator: Up to 360/280 mm
  • Top radiator: Up to 360/420 mm (with cooling bracket installed)
  • Rear radiator: 120 mm
  • Bottom radiator: Up to 240/280 mm

Vertically inclined

Vertical 2.5 slot GPU support via Flex vertical PCIe riser (sold separately)

Full speed ahead

USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps

Conceal and expand

Ventilated PSU shroud conceals cables and provides additional SSD mounting options

Dual layout design

Converting between Open and Storage layout is both fast and easy, ensuring you always get the very most out of your Vector RS.

  • Six HDD and two SSD mounts included with a total of 11 HDD and 4 SSD positions (additional Type A brackets sold separately)
  • Modular design easily converts from a storage-focused standard layout to a cooling-centric open layout
  • Six vibration damped 3.5” HDD trays and two 2.5” SSD brackets included
  • Universal HDD/SSD trays can be independently repositioned to suit your configuration

A new cooling angle

Thanks to the counter-angled intake vents, the Vector RS is a case that can breathe like it's open, but sound like it's closed.

  • Designed to trap noise with minimal airflow resistance
  • Three pre-installed Fractal Design Dynamic X2 GP-14 140 mm fans for optimal airflow
  • Up to nine fan positions with clear airflow paths for maximum cooling capacity
  • Nexus+ fan hub manages up to nine fans via your motherboard
  • High-density industrial sound damping bitumen on the right-hand side panel
  • Easy-to-clean high-airflow nylon filters on the front, top and base

Main Features

  • Tinted, bolt-free tempered glass on three sides
  • Top panel easily converts between tempered glass and filtered ventilation
  • Counter-angled vents designed to trap noise with minimal airflow resistance
Technical Specification

Fractal Design Vector RS Gaming Case - Black

Storage

Internal Expansion Bays2 x 2.5"
6 x 2.5"/3.5"

Expansion

Expansion Slots7 x Full Height
2 x Vertical

Interfaces/Ports

USB Ports1 x USB 3.1 Type-C
2 x USB 3.0
Headphone Ports1 x 3.5mm Jack
Microphone In Port1 x 3.5mm Jack

Electrical

Cooling SystemFront: Supports 3 x 120mm or 140mm fans (2 x 140mm fans included)
TOp: Supports 3 x 120mm or 140mm fans
Rear: Supports 1 x 120mm or 140mm fan (140mm fan included)
Bottom: Supports 2 x 120mm or 140mm fans
Power SupplyATX Power Supply supported

Physical

Form FactorMid Tower Case
Case ColourBlack
MaterialSteel
Tempered Glass
Motherboard CompatibilityE-ATX (up to 285 mm wide)
ATX
MicroATX
Mini-ITX
In The BoxVector RS Blackout computer case
Ventilated top panel
Top filter
Top radiator/fan bracket
Adjust R1 RGB controller
User manual
Accessory box
Width233 mm
Depth552 mm
Height498 mm
Weight12.64 kg

Key Features

FirewireNo
Main ColourBlack
Case TypeTower
USB 3.0 SupportYes
Case Form FactorMid Tower
Power Supply IncludedNo
Optimised forGaming
80Plus RatedNo
PSU Form FactorATX
Display Model in ShowroomNo
IlluminatedYes
e-SATANo
L.E.D FanNo LED
Max 3.5" Drives6
Max 2.5" Drives2
ATXYes
Micro-ATXYes
ITXYes
E-ATXYes
Cooler Height185 mm
Built-in Card ReaderNo
USB Type-C SupportYes
Front HDMINo
Side Panel TypeTempered Glass
GPU Length440 mm
PSU Depth300 mm
Front Audio TypeSeparate
Maximum Motherboard Size SupportedE-ATX

Warranty

Warranty1 Year

Item Details

ManufacturerFractal Design
Manufacturer CodeFD-C-VER1A-01
EAN7340172701965
UPC843276101961
ConditionNew
