NZXT H510 Flow Mid Tower Case - Black
- Part Number: CA-H52FB-01
- Manufacturer: NZXT
- Quickfind Code: 105578
- Stock: Out Stock
Contact for availability
Product Features:
- Condition: New
- Form Factor ATX
- Main Colour Black
- Side Panel Tempered Glass
Share:
For sales and support
Call:0161 480 8800
Product Description
This compact mid-tower is an ideal case for high-performance builds and features a perforated front panel for maximized airflow. The H510 is easy to build in and offers flexibility for a variety of ATX parts.
Main Features
- An optimized perforated top panel delivers increased airflow to your system for improved temperatures
- Iconic cable management bar and uninterrupted tempered-glass side panel
- Cable routing kit with pre-installed channels and straps
- Two Aer F120mm fans and removable filters on all air intakes
- Removable bracket designed for radiators up to 280mm **Case version fans and specs vary from retail version
Technical Specification
NZXT H510 Flow Mid Tower Case - Black
Storage
| Internal Expansion Bays | 2 x 2.5" 2 x 3.5" 1 x 2.5"/3.5" |
Expansion
| Expansion Slots | 7 x Full Height |
Interfaces/Ports
| USB Ports | 1 x USB-C 3.1 1 x USB 3.0 |
| Headphone Ports | 1 x 3.5mm Jack, shared with Microphone |
| Microphone In Port | 1 x 3.5mm Jack, shared with Headphone |
Electrical
| Cooling System | Front: Supports 2 x 140mm or 120mm fans (1 x 120mm fan included) Top: Supports 1 x 140mm or 120mm fan Rear: Supports 1 x 120mm fan (included) |
| Power Supply | ATX Power Supply supported |
Physical
| Form Factor | Mid Tower Case |
| Case Colour | Black |
| Material | SGCC Steel Tempered Glass |
| Motherboard Compatibility | ATX MicroATX Mini-ITX |
| In The Box | H510 Flow Case Headset Audio Jack Splitter Breakout Cable Installation Accessories Manual |
| Width | 210 mm |
| Depth | 428 mm |
| Height | 460 mm |
| Weight | 6.6 kg |
Warranty
| Warranty | 2 Years |
Key Features
| Firewire | No |
| Main Colour | Black |
| Case Type | Tower |
| USB 3.0 Support | Yes |
| Case Form Factor | Mid Tower |
| Power Supply Included | No |
| 80Plus Rated | No |
| PSU Form Factor | ATX |
| Display Model in Showroom | No |
| Illuminated | No |
| e-SATA | No |
| L.E.D Fan | No LED |
| Max 3.5" Drives | 3 |
| Max 2.5" Drives | 3 |
| ATX | Yes |
| Micro-ATX | Yes |
| ITX | Yes |
| Cooler Height | 165 mm |
| Built-in Card Reader | No |
| USB Type-C Support | Yes |
| Front HDMI | No |
| Side Panel Type | Tempered Glass |
| GPU Length | 360 mm |
| Front Audio Type | Combined |
| Number of Fans | 2 fan(s) |
| LED Controller Included | No |
| LED Strip(s) Included | No |
| Maximum Motherboard Size Supported | ATX |
| Total 2.5" + 3.5" drive bays | 5 |
| Power Requirement (auto) | 6 W |
| USB3.0 ports | 1 |
| USB-C ports | 1 |
| Low profile expansion | No |
Item Details
| Manufacturer | NZXT |
| Manufacturer Code | CA-H52FB-01 |
| EAN | 5060301699247 |
| Condition | New |
