NZXT H510i Gaming Case
- Part Number: CA-H510i-BR
- Manufacturer: NZXT
- Quickfind Code: 105182
- Stock: Out Stock
Contact for availability
Product Features:
- Condition: New
- Form Factor ATX
- Main Colour Black
- Side Panel Tempered Glass
Share:
For sales and support
Call:0161 480 8800
Product Description
We’ve made our iconic H Series PC cases even better. Our new lineup still features the elements builders loved in the original H Series, including our patented cable management system, removable fan/radiator mounting brackets, and easy-to-use drive trays, alongside new updates like a front-panel USB-C connector supporting high-speed USB 3.1 Gen 2 devices, a tempered glass side panel that installs with a single thumbscrew, and an upgraded Smart Device V2.
Main Features
- The new Smart Device V2 includes a faster microprocessor for NZXT CAM-powered control of two HUE 2 RGB lighting channels and three fan channels that support either voltage regulated or PWM fans.
- With a USB 3.1 Gen2-compatible USB-C connector on the front panel, it's easier than ever to connect smartphones, high-speed external storage, or the latest peripherals to your PC
- The clean, modern design, iconic cable management bar, and uninterrupted tempered-glass side panel showcase your stunning build.
- Use the intuitive NZXT CAM application to monitor and control your build, choosing from presets or custom controls for your RGB lighting and fans to create your dream PC.
- Cable management can often take more time than assembly. We designed a cable routing kit with pre-installed channels and straps, for intuitive and easy wiring.
- Two Aer F120mm fans are included for optimal internal airflow and the front panel and PSU intakes include removable filters. Includes a removeable bracket designed for radiators up to 280mm simplifies the installation of either closed-loop or custom-loop water cooling.
- Show off your graphic card with a built-in mounting bracket for installing your GPU vertically. *PCIe riser card not included.
Technical Specification
NZXT H510i Gaming Case
Storage
| Internal Expansion Bays | 2 x 2.5" 2 x 3.5" |
Expansion
| Expansion Slots | 7 x Full Height 2 x Vertical Full Height |
Interfaces/Ports
| USB Ports | 1 x USB 3.1 Type-C 1 x USB 3.0 |
| Headphone Ports | 1 x 3.5mm COMBO Jack |
| Microphone In Port | Shared with Headphones |
Electrical
| Cooling System | Front: Supports 2 x 120mm or 140mm fans Top: Supports 1 x 120mm or 140mm fan (120mm fan included) Rear: Supports 1 x 120mm fan (included) |
| Power Supply | ATX Power Supply supported |
Physical
| Form Factor | Mid Tower Case |
| Case Colour | Matte Black with Red Trim |
| Material | SGCC Steel Tempered Glass |
| Motherboard Compatibility | ATX MicroATX Mini-ITX |
| In The Box | Case Installation Screws 10 x Cable Ties 1 x 4-pole to 3-pole Headset Audio Jack Splitter Smart Device V2 2 x Addressable LED Strips |
| Width | 210 mm |
| Depth | 428 mm |
| Height | 460 mm |
| Weight | 6.8 kg |
Warranty
| Warranty | 2 Years |
Key Features
| Firewire | No |
| Main Colour | Red |
| Case Type | Tower |
| USB 3.0 Support | Yes |
| Case Form Factor | Mid Tower |
| Power Supply Included | No |
| Optimised for | Gaming |
| 80Plus Rated | No |
| PSU Form Factor | ATX |
| Display Model in Showroom | No |
| e-SATA | No |
| L.E.D Fan | No LED |
| Internal 3.5" Bay | 2 |
| Internal 2.5" Bay | 2 |
| ATX | Yes |
| Micro-ATX | Yes |
| ITX | Yes |
| Cooler Height | 165 mm |
| Built-in Card Reader | No |
| USB Type-C Support | Yes |
| Front HDMI | No |
| Side Panel Type | Tempered Glass |
| GPU Length | 381 mm |
| Front Audio Type | Separate |
| Maximum Motherboard Size Supported | ATX |
Item Details
| Manufacturer | NZXT |
| Manufacturer Code | CA-H510i-BR |
| EAN | 5060301695034 |
| UPC | 815671014733 |
| Condition | New |
