This compact mid-tower is an ideal case for high-performance builds and features a perforated front panel for maximized airflow. The H511 is easy to build in and offers flexibility for a variety of ATX parts.
*Case version fans and specs vary from retail version
NZXT H511 Flow Mid Tower Case - Black USB 3.0
User Controls
| User Controls | Power |
Storage
| Internal Expansion Bays | 2 x 2.5" 1 x 2.5"/3.5" 2 x 3.5" |
Expansion
| Expansion Slots | 7 x Full Height |
Interfaces/Ports
| USB Ports | 2 x USB 3.0 |
| Headphone Ports | 1 x 3.5mm Jack, shared wtih Microphone |
| Microphone In Port | 1 x 3.5mm Jack, shared wtih Headphone |
Electrical
| Cooling System | Front: Supports 2 x 140mm or 120mm fans (1 x 120mm fan included) Top: Supports 1 x 140mm or 120mm fan Rear: Supports 1 x 120mm fan (included) |
| Power Supply | ATX Power Supply supported |
Physical
| Form Factor | |
| Case Colour | Case |
| Material | SGCC Steel Tempered Glass |
| Motherboard Compatibility | ATX MicroATX Mini-ITX |
| Width | 210 mm |
| Depth | 428 mm |
| Height | 460 mm |
| Weight | 6.6 kg |
Warranty
| Warranty | 2 Years |
Key Features
| Firewire | |
| Power | W |
| Laptop Size Range | ins |
| Main Colour | Black |
| External Expansion Bays | |
| Case Type | Tower |
| USB 3.0 Support | Yes |
| Case Form Factor | Mid Tower |
| Power Supply Included | No |
| Optimised for | |
| Modular Cables | |
| 80Plus Rated | No |
| Bag Size | |
| PSU Form Factor | ATX |
| Display Model in Showroom | |
| Illuminated | No |
| e-SATA | |
| L.E.D Fan | No LED |
| Laptop Size | |
| Max 3.5" Drives | 3 |
| External 5.25" Bay | |
| Max 2.5" Drives | 2 |
| ATX | Yes |
| Micro-ATX | Yes |
| ITX | Yes |
| E-ATX | |
| XL-ATX | |
| Mini PC | |
| Cooler Height | 165 mm |
| Built-in Card Reader | No |
| USB Type-C Support | No |
| Front HDMI | No |
| Side Panel Type | Tempered Glass |
| GPU Length | 360 mm |
| PSU Depth | mm |
| Memory Speed | MHz |
| Card Reader Type | |
| Front Audio Type | Combined |
| Number of Fans | 2 fan(s) |
| LED Controller Included | No |
| LED Strip(s) Included | No |
| Maximum Motherboard Size Supported | ATX |
| RGB Software Type | |
| Total 2.5" + 3.5" drive bays | 5 |
| Power Requirement (auto) | 6 W |
| USB3.0 ports | 1 |
| USB-C ports | 1 |
| Low profile expansion | No |
Item Details
| Manufacturer | NZXT |
| Manufacturer Code | CA-H52FB-11 |
| EAN | 5060301699261 |
| UPC | 815671019592 |
| Condition | New |
