Phanteks NV5 MKII Mid Tower Gaming Case - White

Part Number: PH-NV523TG_DMW02
Manufacturer: Phanteks
Quickfind Code: 105924

Stock: In Stock

£93.89 ex. vat
£112.67 inc. vat

Product Features:

Condition: New
Form Factor E-ATX
Main Colour White
Side Panel Tempered Glass

+ Read More Information

Product Description

Meet the NV5 mid-tower chassis, featuring a stunning near-seamless glass view and support for 8 x 120 mm fans and dedicated space for a 360 radiator in the top and side for optimal cooling. With a dedicated bottom fan for enhanced GPU cooling and spacious interior to accommodate modern GPUs and cables, the NV5 is designed to excel.

Its PSU cover opens for easy cable management, and its DRGB lighting system is customizable and easy to sync. With its sleek design and convenient features, the NV5 is the perfect choice for a high-performance PC build that looks as good as it performs.

PERFECT VIEW OF YOUR SYSTEM

Near-seamless glass panels for a perfect view of all your system components.
Top and side panel with Ultra-fine performance mesh for high airflow and good dust filtration.
A total of eight 120 mm fan positions for high-end cooling performance.
Dual 360 radiator support in the top and side.

READY FOR MODERN GPUS

Increased chassis width to support wider GPUs and 12VHPWR cables.
GPU support bracket supports and holds the GPU securely to chassis and motherboard.
Dedicated GPU fan to provide direct airflow to the GPU from the bottom.
Removable PSU cover for easy access to power cables.

BUILD FOR THE FUTURE

UNLOCK THE ZERO-CABLE SETUP - Mainboards with hidden connectors on the rear-side are fully supported by the NV chassis.
Support for MSI Project Zero mainboards.
Support for ASUS BTF mainboards.

INTEGRATED D-RGB LIGHTING

Built-in Digital-RGB Controller.
Refined D-RGB lighting effects that just work, no software required.
Expand with more Digital-RGB lighting.
Optionally sync with motherboard and software.

MULTIPLE STORAGE OPTIONS

Support for 4x 2.5″ SSD.
Support 3x 3.5″ HDDs.

Technical Specification

Phanteks NV5 MKII Mid Tower Gaming Case - White

User Controls

Power
D-RGB Mode
D-RGB Colour

Storage

Internal Expansion Bays

4 x 2.5"
3 x 3.5"

Expansion

Expansion Slots

7 x Full Height

Interfaces/Ports

USB Ports	1 x USB-C 3.1 2 x USB 3.0
Headphone Ports	1 x 3.5mm COMBO Jack
Microphone In Port	Shared with Headphone

Electrical

Cooling System	Top: Supports 3 x 120mm fans Side: Supports 3 x 120mm fans Rear: Supports 1 x 120mm fan Bottom: Supports 1 x 120mm fan
Power Supply	ATX Power Supply supported

Warranty

5 Years

Physical

Form Factor	Mid Tower Case
Case Colour	Matte White
Material	Steel Tempered Glass
Motherboard Compatibility	E-ATX (up to 280mm) ATX mATX Min-ITX
In The Box	Case Accessory Kit
Width	239 mm
Depth	477 mm
Height	528 mm
Weight	11.28 kg

Key Features

Max Motherboard Width	330 mm
Max Motherboard Height	305 mm
Supports AIO Cooler	Yes
Main Colour	White
Case Type	Tower
Case Form Factor	Mid Tower
Power Supply Included	No
Optimised for	Gaming
80Plus Rated	No
PSU Form Factor	ATX
Illuminated	Yes
L.E.D Fan	No LED
Max 3.5" Drives	3
Max 2.5" Drives	4
ATX	Yes
Micro-ATX	Yes
ITX	Yes
E-ATX	Yes
Cooler Height	180 mm
Built-in Card Reader	No
USB Type-C Support	Yes
Side Panel Type	Tempered Glass
GPU Length	440 mm
PSU Depth	230 mm
RGB LED Controller Included	Yes
LED Strip(s) Included	No
Maximum Motherboard Size Supported	E-ATX
RGB Software Type	None
Total 2.5" + 3.5" drive bays	7
USB3.0 ports	2
USB-C ports	1
Low profile expansion	No
Max Supported Radiator Length	360 mm
Create Your Own Gaming PC (CCL)	Yes
Back Connect Support	No
