Fractal Design Silent Series R3 (92mm) Case Fan
- Part Number: FD-FAN-SSR3-92-WT
- Manufacturer: Fractal Design
- Quickfind Code: 120495
- Stock: In Stock
£5.89 ex. vat
£7.07 inc. vat
Share:
For sales and support
Call:0161 480 8800
Product Description
Fractal Design Silent Series R3 (92mm) Case Fan
Fractal Design Silent Series R3 (92mm) Case Fan
Fractal Design Silent Series R3 fans offer excellent value for money, with good performance and assured reliability.
All Fractal Design Silent Series R3 fans are equipped with long-life rifle bearings and an easy-to-hide, sleek black cable.
Available in a large variety of sizes, ranging from compact 40mm fans to full-size 140mm fans, the Silent Series R3 delivers suitable options for replacing loud or damaged fans in both computers and many other electronic devices.
Featuring rifle bearings, providing improved life expectancy and lower noise compared to a standard sleeve bearing
Black stealth ribbon cable, making it easy to hide the cable contributing to a clean build
Improved, more balanced, sturdy fan design delivering precision at a good price point
Low fan speeds, optimized for quiet operation
Featuring Fractal Design's signature black and white color scheme
Offering sizes from 40mm up to 140mm for all your build needs
Specifications
Design
Cable length 0.35 m
Colour of product Black, White
Other features
Bearing technology Rifle
Performance
Fan diameter 9.2 cm
Maximum air pressure 0.79 mmH2O
Maximum airflow 24.4 cfm
Maximum spin speed 1500 RPM
Mean time between failures (MTBF) 40000 h
Mounting hole pattern (WxD) 82.5 x 82.5 mm
Noise level (high speed) 18.3 dB
Suitable for Computer case
Type Fan
Power
Maximum current 0.07 A
Power supply 0.6 W
Voltage 12
Technical details
Fan connector 3-pin
Weight & dimensions
Depth 9.2 cm
Height 2.5 cm
Package depth 9.4 cm
Package height 2.6 cm
Package width 12.1 cm
Weight 150 g
Width 9.2 cm
Fractal Design Silent Series R3 fans offer excellent value for money, with good performance and assured reliability.
All Fractal Design Silent Series R3 fans are equipped with long-life rifle bearings and an easy-to-hide, sleek black cable.
Available in a large variety of sizes, ranging from compact 40mm fans to full-size 140mm fans, the Silent Series R3 delivers suitable options for replacing loud or damaged fans in both computers and many other electronic devices.
Featuring rifle bearings, providing improved life expectancy and lower noise compared to a standard sleeve bearing
Black stealth ribbon cable, making it easy to hide the cable contributing to a clean build
Improved, more balanced, sturdy fan design delivering precision at a good price point
Low fan speeds, optimized for quiet operation
Featuring Fractal Design's signature black and white color scheme
Offering sizes from 40mm up to 140mm for all your build needs
Specifications
Design
Cable length 0.35 m
Colour of product Black, White
Other features
Bearing technology Rifle
Performance
Fan diameter 9.2 cm
Maximum air pressure 0.79 mmH2O
Maximum airflow 24.4 cfm
Maximum spin speed 1500 RPM
Mean time between failures (MTBF) 40000 h
Mounting hole pattern (WxD) 82.5 x 82.5 mm
Noise level (high speed) 18.3 dB
Suitable for Computer case
Type Fan
Power
Maximum current 0.07 A
Power supply 0.6 W
Voltage 12
Technical details
Fan connector 3-pin
Weight & dimensions
Depth 9.2 cm
Height 2.5 cm
Package depth 9.4 cm
Package height 2.6 cm
Package width 12.1 cm
Weight 150 g
Width 9.2 cm
Technical Specification
Fractal Design Silent Series R3 (92mm) Case Fan
Fractal Design Silent Series R3 (92mm) Case Fan
General | |
|---|---|
| Package Content | 4 screws |
| Product Type | Case fan |
| Width | 9.2 cm |
| Depth | 9.2 cm |
| Height | 2.5 cm |
| Weight | 80 g |
| Colour | Black, white |
Security Cable Lock | |
| Fan Diameter | 92 mm |
| Fan Height | 25 mm |
| Fan Bearing | Rifle bearing |
| Rotation Speed | 1500 rpm |
| Air Flow | 24.4 cfm |
| Air Pressure | 0.79 mm |
| Noise Level | 18.3 dBA |
| Power Connector | 3-pin plug |
| Rated Voltage | 12 V |
| Start Voltage | 6 V |
| Rated Current | 0.07 A |
| Power Consumption | 0.6 W |
| Cable Length | 35 cm |
Heatsink & Fan | |
| Fan Diameter | 92 mm |
| Fan Height | 25 mm |
| Fan Bearing | Rifle bearing |
| Rotation Speed | 1500 rpm |
| Air Flow | 24.4 cfm |
| Air Pressure | 0.79 mm |
| Noise Level | 18.3 dBA |
| Power Connector | 3-pin plug |
| Rated Voltage | 12 V |
| Start Voltage | 6 V |
| Rated Current | 0.07 A |
| Power Consumption | 0.6 W |
| Cable Length | 35 cm |
Miscellaneous | |
| MTBF | 40,000 hour(s) |
