Axial-tech Fan Design
Two tried-and-true Axial-tech fans feature a smaller hub that facilitates longer blades and a barrier ring to increase downward air pressure.
Quiet intelligence
An advanced onboard controller brings fans to a standstill when the GPU core temperature is below 55 Celsius, letting you enjoy light gaming in relative silence. As temps rise past the threshold, the fans automatically start up again.
Dual Ball Fan Bearings
Different bearing types have unique pros and cons. Ball bearings excel at durability and can last up to twice as long as sleeve bearing designs.
2.5-slot Design
A carefully designed shroud, heatsink, and heatpipe layout allows the two Axial-tech fans to leverage chassis side-panel ventilation and deliver thermal performance that belies the card's size.
ASUS NVIDIA GeForce RTX 4070 SUPER 12GB Graphics Card
GPU
| Chipset Manufacturer | NVIDIA |
| Chipset Model Name | GeForce RTX |
| Chipset Model Number | 4070 SUPER |
| Chipset Additional Information | Dual EVO OC |
| Boost Chip Clock | 2520 MHz |
| Graphics Core | CUDA |
| Number of Cores | 7168 |
| Cooling System | Dual Axial Fan Tech |
Memory
| Memory Size | 12288 MB |
| Memory Clock | 21 Gbps |
| Memory Type | GDDR6X |
| Memory Width | 192 bit |
Interfaces/Ports
| Video Card Bus Type | PCI Express |
| Video Card Bus Version | 4.0 x16 |
| HDMI Port | 1 x HDMI 2.1a |
| DisplayPort | 3 x DisplayPort 1.4a |
Resolution
| Multiple Monitor Support (Max) | Yes (4) |
| Maximum Resolution | 7680 x 4320 |
System Requirements
| System Requirements | 1 x PCI Express 4.0 x16 slot Recommended 750W or greater PSU with 1 x 12VHPWR or 2 x 8-pin PCIe connectors |
Electrical
| Power Connector | 1 x 12VHPWR or 2 x 8-pin PCIe |
| Power Consumption | 220 W |
| Recomended Power Supply | 750 W |
Physical
| Form Factor | Graphics Card |
| In The Box | Graphics Card Speedsetup Manual Thank you card Adapter Cable (1 to 2) |
| Width | 49.6 mm (2.5 slot) |
| Depth | 227.2 mm |
| Height | 123.24 mm |
Warranty
| Warranty | 3 Years |
Key Features
| Interface Type | PCI Express 4.0 x16 |
| Config Gaming x8 (CB/CCL) | Yes |
| Graphics Memory Type | GDDR6X |
| Main Colour | Black |
| VGA Connection | No |
| DVI Connection | No |
| HDMI Connection | Yes |
| Graphics Usability | Gaming |
| DisplayPort Connection | Yes |
| Direct X Support | Direct X 12 |
| Cooler Type | Dynamic Fan Inc. 0dB Mode |
| Low Profile | No |
| NVIDIA GeForce | RTX 4070 SUPER |
| PCIe Pin Type | 12+4-Pin (16-Pin) |
| Screen Type | Other |
| Cooling Technology | Dynamic Fan Inc. 0dB Mode |
| VR Ready | NVIDIA |
| GPU Length | 228 mm |
| Card Width | 3 |
| Power Requirement (auto) | 220 W |
| GPU Power (TDP) | 220 W |
| Graphics card count | 1 |
| PCI Express Power Pins (female) | 16 |
| PCIe Physical Slot required | 16 |
| 12VHPVR 16-pin Connector | Yes |
| AI Ready | Yes |
Graphics
| Graphics Chipset | GeForce RTX 4070 SUPER |
Graphics Device
| G-Sync | Yes |
Item Details
| Manufacturer | ASUS |
| Manufacturer Code | 90YV0KC0-M0NA00 |
| Alternative Part Number | DUAL-RTX4070S-O12G-EVO |
| EAN | 4711387475997 |
