Gainward GeForce RTX 3080 Ti Phantom 12GB GPU

  • Part Number: NED308T019KB-1020M
  • Manufacturer: Gainward
  • Quickfind Code: 125275

  • Stock: Out Stock

Contact for availability


Product Features:
  • Condition: New
  • GPU RTX 3080 Ti
  • Capacity 12GB
  • Connection PCI-E
  • Memory Type GDDR6X
  • Series RTX
  • GPU Manufacturer Nvidia
+ Read More Information

Share:

Product Description





Reinforced Fan Blade

The Advanced Fan Blade design increases the stability of fan rotation. With the carves on the blades, the air flow is smoother. So fan vibration and fan noises are much lower.

ARGB Lighting SYNC

ARGB SYNC allows you to sync the lighting effect with all A-RGB devices in your PC system and enjoy the lighting symphony!

Two Ball Bearing

2-ball bearing to bring longer life span for the fan

  • IP5X dust resistant technology
  • Lower fan vibration
  • Prolonged fan life expectancy

ARGB Lighting

Addressable RGB allows gamers to customize each LED color. You can personalize the lighting effects with GAINWARD Expertool Utility

Max-Efficiency Heatsink

The fin design is molded with embossments to enlarge air contact area for most efficient heat dissipation

ZERO RPM FAN

The fans Keep stop rotation while you are experiencing the multimedia application or general workload. The fans start rotation while working on heavier loading such as gaming that the GPU temperature surpasses 60°C

Metal Plate Kit

Two die casting molded plates fully cover the circuit board and directly attach to all the hot spots on PCB.

They provide:

  • Strong-as-armor protection
  • Optimized heat dissipation
Technical Specification

Gainward GeForce RTX 3080 Ti Phantom 12GB GPU

GPU

Chipset ManufacturerNVIDIA
Chipset Model NameGeForce RTX
Chipset Model Number3080 Ti
Chipset Additional InformationPhantom
Boost Chip Clock1665 MHz
Graphics CoreCUDA

Memory

Memory Size12288 MB
Memory Clock19 Gbps
Memory TypeGDDR6X
Memory Width384 bit
Memory Bandwidth912 GB/s

Interfaces/Ports

Video Card Bus TypePCI Express
Video Card Bus Version4.0 x16
HDMI Port1 x HDMI 2.1
DisplayPort3 x DisplayPort 1.4a

Resolution

Multiple Monitor Support (Max)Yes (4)
Maximum Resolution7680 x 4320 pixels

System Requirements

System Requirements1 x PCI Express 4.0 x16 slot
Recommended 850W PSU with 3 x 8-pin PCIe connectors

Electrical

Power Connector3 x 8-pin PCIe
Recomended Power Supply850 W

Physical

Form FactorGraphics Card
In The BoxGraphics Card
Width2.7 slot
Depth304 mm
Height138 mm

Warranty

Warranty2 Years

Key Features

Interface TypePCI Express 4.0 x16
VGA ConnectionNo
DVI ConnectionNo
HDMI ConnectionYes
Graphics UsabilityGaming
DisplayPort ConnectionYes
Direct X SupportDirect X 12
Cooler TypeDynamic Fan
Low ProfileNo
NVIDIA GeForceRTX 3080 Ti
PCI-E Pin Type8-Pin x 3
Cooling TechnologyDynamic Fan
VR ReadyNVIDIA
GPU Length304 mm
Card WidthTriple Slot

Graphics

Graphics ChipsetGeForce RTX 3080 Ti

Graphics Device

G-SyncYes

Compatibility

Lite Hash RateYes

Item Details

ManufacturerGainward
Manufacturer CodeNED308T019KB-1020M
EAN4710562242393
ConditionNew
