WINDFORCE 3X COOLING SYSTEM
The WINDFORCE 3X cooling system features three unique blade fans, alternate spinning, composite copper heat pipe directly touches GPU, Screen cooling and 3D active fan, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Alternate Spinning can reduce the turbulence of adjacent fans and increase air pressure.
SMOOTH AIRFLOW
GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
SCREEN COOLING
Extended heatsink design allows air flow to pass through, providing better heat dissipation.
HEAT PIPES AND COPPER PLATE
The shape of the pure copper heat pipe contacts with the GPU through a copper plate.
PROTECTION BACK PLATE
The back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection
ULTRA COOLING
Lower RDS(on) MOSFETs are specially designed to produce lower switching resistance for faster electric current charging and discharging at extremely low temperature.
LOW POWER LOSS
Metal Choke hold energy much longer than common iron-core chokes at high frequency, thus effectively reduce core energy loss and EMI interference.
LONGER LIFE
Lower ESR Solid Capacitors ensure better electronic conductivity for excellent system performance and longer lifespan.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
Main Features
Powered by AMD RDNA 2 Radeon RX 6500 XT
Integrated with 4GB GDDR6 64-bit memory interface
WINDFORCE 3X Cooling System with alternate spinning fans
Screen cooling
Graphene nano lubricant
Protection back plate
Gigabyte Radeon RX 6500 XT Gaming OC 4GB OC GPU
GPU
| Chipset Manufacturer | AMD |
| Chipset Model Name | Radeon RX |
| Chipset Model Number | 6500 XT |
| Chipset Additional Information | GAMING OC |
| Chip Clock | 2685 MHz |
Storage
| Memory Size | 4096 MB |
Memory
| Memory Clock | 18 Gbps |
| Memory Type | GDDR6 |
| Memory Width | 64 bit |
| Memory Bandwidth | 144 GB/s |
Interfaces/Ports
| Video Card Bus Type | PCI Express |
| Video Card Bus Version | 4.0 x4 |
| HDMI Port | 1 x HDMI 2.1 |
| DisplayPort | 1 x DisplayPort 1.4a |
System Requirements
| System Requirements | 1 x PCI Express 4.0 x16 slot Recommended 400W or greater PSU with 1 x 6-pin PCIe connector |
Resolution
| Multiple Monitor Support (Max) | Yes (2) |
| Maximum Resolution | 7680 x 4320 pixels |
Physical
| Form Factor | Graphics Card |
| In The Box | Graphics Card Quick Guide |
| Width | 40 mm (Dual Slot) |
| Depth | 282 mm |
| Height | 114 mm |
Warranty
| Warranty | 3 Years |
Key Features
| Interface Type | PCI Express 4.0 |
| VGA Connection | No |
| DVI Connection | No |
| HDMI Connection | Yes |
| Graphics Usability | Gaming |
| DisplayPort Connection | Yes |
| Direct X Support | Direct X 12 |
| Cooler Type | Dynamic Fan |
| Low Profile | No |
| AMD Radeon | RX 6500 XT |
| PCI-E Pin Type | 6-Pin |
| FreeSync | Yes |
| Cooling Technology | Dynamic Fan |
| GPU Length | 282 mm |
| Card Width | Dual Slot |
Graphics
| Graphics Chipset | Radeon RX 6500 XT |
Item Details
| Manufacturer | Gigabyte |
| Manufacturer Code | GV-R65XTGAMING OC-4GD |
| EAN | 4719331310561 |
| UPC | 889523031254 |
| Condition | New |
