Features• Heavy Plated Heatsinks: Leading heatsink design, for maximum cooling.
• DDR4 Boost with Steel Armor: Optimized traces and isolated memory circuitry.
• Turbo M.2 with Steel Armor: Optimized traces and isolated memory circuitry, ready for Intel® Optane™ Memory.
• PCI-E Steel Armor: Protecting VGA cards against bending and EMI.
• Audio Boost: Reward your ears with studio grade sound quality.
• Double ESD Protection: Double grounding layered mounting holes prevent ESD damage.
• Intel® LAN.
• Lightning USB 3.1 Gen2.
• USB 3.1 Type-C.
• Golden audio jacks, 7.1 surround.
MSI B250 PC Mate Intel B250 Socket 1151 DDR4 ATX Motherboard
| CPU | o Supports 6th/7th Gen Intel® Core™ i3/i5/i7 processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151 |
| Chipset | o Intel® B250 Chipset |
| Memory | o 4 x DDR4 memory slots, support up to 64GB- 7th Gen processors support DDR4 2400/ 2133 MHz*- 6th Gen processors support DDR4 2133 MHz*o Dual channel memory architectureo Supports Intel® Extreme Memory Profile (XMP)* Please refer www.msi.com for more information on compatible memory. |
| Onboard Graphics Outputs | o 1 x HDMI™ port, supports a maximum resolution of 4096x2160@30Hz(7th CPU), 4096x2160@24Hz(6th CPU), 2560x1600@60Hzo 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hzo 1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz |
| Multi-GPU Support | o Supports 2-Way AMD® CrossFire™ Technology |
| PCI Slots | o 2 x PCIe 3.0 x16 slots (supports x16/x4 mode)*o 3 x PCIe 3.0 x1 slots**o 1 x PCI slot* The PCI_E4 slot will be unavailable when an M.2 PCIe SSD module has been installed in the M.2_2 slot.** The PCI_E2/ PCI_E5 slot will be unavailable when an expansion card has been installed in the PCI_E3/ PCI1 slot. |
| Storage | o Intel® B250 Chipseto 6 x SATA 6Gb/s ports*o 2 x M.2 slots (Key M)- Support up to PCIe 3.0 x4 and SATA 6Gb/s- Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host Card**- M2_1 slot supports 2242/ 2260 /2280/ 22110 storage devices- M2_2 slot supports 2242/ 2260 /2280 storage devices- Intel® Optane™ Memory Readyo Supports Intel® Smart Response Technology for Intel Core™ processors (optional)* M.2 and SATA ports maximum support 2x M.2 PCIe SSDs + 6x SATA HDDs. Please refer to the manual for M.2 slots with examples of various combination possibilities.** The Turbo U.2 Host Card is not included, please purchase separately. |
| USB | o ASMedia® ASM2142 Chipset- 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C port on the back panelƒ- 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-A port on the back panelo Intel® B250 Chipset- 6 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connector) (optional)- 6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connector) |
| Audio | o Realtek® ALC887 Codec- 7.1-Channel High Definition Audio |
| LAN | o 1 x Intel® I219-V Gigabit LAN controller |
| Form Factor | o 12 in. x 9.6 in. (30.4 cm x 24.3 cm)o ATX Form Factor |
