850W Be Quiet! Pure Power 12 80+ Gold PSU

Part Number: BP004EU
Manufacturer: BeQuiet!
Quickfind Code: 140534

Stock: In Stock

£90.56 ex. vat
£108.67 inc. vat

Product Features:

Condition: New
Capacity 850W
Connection Fully Wired
Form Factor ATX 3.1
Certification 80+ Gold
Main Colour Black

+ Read More Information

80 PLUS® GOLD CERTIFIED

Very high operating efficiency

Pure Power 12 850W is certified 80 PLUS Gold with an outstanding efficiency rating of up to 92.7%. The most compelling benefit: lower power consumption, consequently lower costs, and above all a cooler as well as quieter operation. Pure Power 12 850W is always the correct choice for quiet systems and gaming PCs!

FUTURE-PROOF YOUR SYSTEM

Fulfills all ATX 3.1 specifications

Pure Power 12 850W is an ATX 3.1 PSU and comes with both native integration of the 12V-2x6 connector for next-generation PCIe 5.1 graphics cards, and 3 PCIe 6+2-pin connectors for support of current-gen GPUs. This makes the PSU extremely versatile and the perfect choice for powerful systems of today and the ones to come.

THE NEW STANDARD OF POWER

For massive transient loads

Pure Power 12 offers 850W of continuous power with one massive 12V rail. Even if the graphics card demands excessive power for a short time: Pure Power 12 850W handles power excursions up to double its rated power with ease. This ensures reliable operation with the next generation of processors and graphics cards.

EXCEPTIONALLY SILENT OPERATION

Achieved by a silence-optimized be quiet! fan

The exceptionally silent 120mm be quiet! fan is temperature-controlled to strike the best balance between effective cooling and quietness. Airflow-optimized fan blades reduce turbulence, enabling best-in-class quiet functionality.

HIGH-CLASS TECHNOLOGIES

Rock-solid stability

With its LLC topology Pure Power 12 850W provides best-in-class voltage regulation and efficiency. That makes it perfect for building very quiet systems or upgrading gaming and media creation PCs.

HIGH-QUALITY CABLES

For a tidy system

Pure Power 12 850W is certainly an eye-catcher. Motherboard and 12V-2x6 cables are finished with high quality black sleeves. The remaining premium black flat cables simplify installation and keep the system tidy. This results in increased airflow and improved cooling.

Main Features

80 PLUS Gold efficiency (up to 92.7%)
ATX 3.1 PSU with full support for PCIe 5.1 GPUs and GPUs with 6+2 pin connectors
Exceptionally silent 120mm be quiet! fan
Advanced stability and voltage regulation thanks to LLC technology
One massive high-performance 12V-rail
One PCIe 5.1 12V-2x6 600W and 3 PCIe 6+2 connectors for overclocked high-end GPUs
10-year manufacturer's warranty

Technical Specification

850W Be Quiet! Pure Power 12 80+ Gold PSU

Interfaces/Ports

SATA Connectors	6
CPU Connectors	1 x 4+4-pin EPS 1 x 8-pin EPS
PCI Connectors	3 x 6+2-pin PCIe
Motherboard Connectors	1 x 24-pin ATX
Molex Connectors	1
Other Connectors	1 x 12V-2x6

Compliance

ATX Spec	ATX 3.1
Standards	80 PLUS Gold Certified
Safety	OTP, OCP, OPP, SCP, OVP, UVP, SIP

Electrical

Voltage	100 ~ 240 V
Power	850 W
Frequency Range	50 ~ 60 Hz

Environmental

Operating Temperature

0 ~ 40 °C

Physical

Form Factor	ATX Power Supply
Case Colour	Black
In The Box	Power Supply Screws Cable Ties User Manual
Width	150 mm
Depth	160 mm
Height	86 mm
Weight	2.7 kg

Warranty

10 Years

Key Features

Main Colour	Black
Modular Cables	No
80Plus Rated	80 Plus Gold
PSU Form Factor	ATX
PCIe Connectors	3
Motherboard (EPS) Power Connectors	4+4-Pin + 8-Pin
PCIe Pin Type	6+2-Pin
PSU Depth	160 mm
CPU Power Pins (male)	16
PCIe Power Pins (male)	24
12VHPWR 16-pin Connector	Yes
Create Your Own Gaming PC (CCL)	Yes
12V-2x6 Rating	450W
