Possible Applications:
Now multiple users can experience shared touchscreen interaction. Using up to 10 finger touchpoints, the HANNSpree HO105HTB Monitor allows everyone to play and collaborate at the same time. The precise and accurate multi-touch display - allowing up to 10 simultaneous touches - is optimised for use with Windows 8, 8.1 and 10, allowing you to work smarter and more efficiently. This technology delivers super-fast, sensitive touch response with excellent dragging performance and perfect picture quality. Ten-point multi-touch support lets you unlock the power of today's touch-enabled applications.
Its rugged bezel with edge-to-edge glass makes it very suitable for applications like tabletop integration. The display supports rear VESA and external mounting brackets for multiple mounting options. The brackets provide the benefits of easy installation and flexibility for different applications.
The Touch monitor HO105HTB features a 16:10 aspect ratio LED-backlit panel with a 170° wide view angle that minimizes colour shift on both horizontal and vertical planes to ensure quality visuals from almost any direction. It delivers improved colour accuracy plus increased energy efficiency. The HO105HTB uses a 170°(H) / 170°(V) wide viewing angle panel that eliminates colour shift from almost any direction and in nearly every angle.
The HANNspree HO105HTB features a host of connectivity options that include HDMI and VGA. The HO105HTB Open Frame Touch Monitor ensures that your monitor is more compatible and ready to handle all of your content. Enabling touch is easy! Simply connect the USB cable from your PC to the monitor's USB upstream port, and connect one of the video inputs to project images onscreen.
6H scratch resistant surface hardness ensures durability, as well as a consistent high-quality touch experience. Scratch resistance is essential for touch solutions used for education and public environment. This is achieved thanks to a glass overlay covering the screen. This means that the panel surface can withstand impact from objects and scratches, making it perfect for public spaces and educational institutions. Our toughened Hard Glass fronted LED Monitors (6H hardness rating) are designed specifically for retail and Industrial applications offering protection from impacts and dirt for a long-life solution. It guarantees high durability of the touch function and even more importantly the touch function remains unaffected even if the glass is scratched.
Hannspree HO105HTB 10.1" HD Touchscreen Open Frame TFT Monitor
General | |
|---|---|
| Bezel Type | Flat front |
| Display Type | LED-backlit LCD monitor / TFT active matrix |
| Energy Class | Class C |
| Energy Consumption per Year | 7 kWh |
| Diagonal Size | 10.1" |
| Panel Type | IPS |
| Aspect Ratio | 16:10 |
| Native Resolution | 1280 x 800 at 60 Hz |
| Pixel Pitch | 0.1695 mm |
| Brightness | 350 cd/m² |
| Brightness w/touchscreen | 300 cd/m² |
| Contrast Ratio | 800:1 |
| Colour Support | 16.7 million colours |
| Response Time | 25 ms |
| Vertical Refresh Rate | 56 - 60 Hz |
| Horizontal Refresh Rate | 30 - 55 kHz |
| Horizontal Viewing Angle | 170 |
| Vertical Viewing Angle | 170 |
| Screen Coating | 6H Hard Coating |
| Backlight Technology | LED backlight |
| Colour Temperature | 9300K, 6500K, 7500K |
| Features | Ultra wide viewing angle, g+g touch screen, metal casing |
| Dimensions (WxDxH) | 26 cm x 3.58 cm x 17.8 cm |
| Weight | 1.4 kg |
Power | |
| Voltage Required | DC 12 V |
| Power Consumption (On mode) | 5 W |
| Input Voltage | DC 12 V |
| Power Consumption SDR (On mode) | 5 kWh/1000h |
| Power Consumption (Typical) | 4.6 Watt |
| Power Consumption Stand by | 0.145 Watt |
| Power Consumption (Off Mode) | 0.04 Watt |
| On / Off Switch | No |
Input | |
| Type | Touch-screen - touchscreen |
| Movement Detection Technology | Capacitance intelligence (PCAP) |
Connectivity | |
| Interfaces | VGA ¦ HDMI ¦ USB (touchscreen only) |
Mechanical | |
| VESA Mounting Interface | 75 x 75 mm |
Miscellaneous | |
| Features | Water-resistant, dust-resistant, landscape / portrait mounting, scratch-resistant |
| Cables Included | 1 x USB cable - 1.8 m ¦ 1 x HDMI cable - 2 m |
| Backlight Life | 20,000 hours |
| Compliant Standards | WEEE, IP65 |
Dimensions & Weight (Shipping) | |
| Shipping Width | 37 cm |
| Shipping Depth | 9 cm |
| Shipping Height | 23.7 cm |
| Shipping Weight | 2.2 kg |
