TP-Link TL-WR940N V4 4-port Wireless Cable Router

Part Number: TL-WR940N V4
Manufacturer: TP Link
Quickfind Code: 605025

Stock: Out Stock

Contact for availability

Product Features:

Condition: New
Connection Wireless AC
Type Wireless Cable Router
Main Colour Black

+ Read More Information

Product Description

The TL-WR940N Wireless N Router is a combined wired/wireless network connection device designed specifically for small business, office and home networking requirements. It provides a simple, very fast, pleasing way to access Internet or Ethernet without cables for work or fun. It complies with the IEEE 802.11n (Draft 2.0) standard with wireless transmission speeds of up to 450Mbps. The router features 4 10/100M switch ports to achieve the most effective data transmission. TL-WR940N adopts MIMO as well as SST technologies, has three external fixed Omni directional antennas providing even better wireless performance, transmission rates, stability and coverage. TL-WR940N also provides a Wireless On/Off button that allows users to easily turn on/off the router's wireless radio whenever necessary.

Main Features

Wireless N speed up to 450Mbps makes it ideal for bandwidth consuming or interruption sensitive applications like video streaming, online gaming and Internet Calls
Wireless On/O Button allows users to simply turn their wireless radio on or o
Easily setup a secure connection at a push of the WPS button
WDS wireless bridge provides seamless bridging to expand your wireless network
IP based bandwidth control allows administrators to determ in how much bandwidth is allotted to each PC
Parental controls allows parents or administrators to establish restricted access policies for children or sta
Supports virtual server, special application and DMZ host ideal for creating a website within your LAN
Oers Auto-mail function for system log, convenient for managing the router
Backward compatible with 802.11b/g products
Easy Setup Assistant provides quick & hassle free installation
Sleek exterior, can be mounted on a wall or placed horizontally on a table or desk

Technical Specification

TP-Link TL-WR940N V4 4-port Wireless Cable Router

Router

Router Type

Cable

WAN

WAN Protocols

Dynamic IP/Static IP/PPPoE/ PPTP(Dual Access)/L2TP(Dual Access)/BigPond

Wireless LAN

Antenna Type	3 x 5dBi Fixed Omni Directional
Transmit Power	20 dB
Data Transfer Rates	Up to 450 Mbps
Encryption	WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
Frequency Band	2.4 to 2.4835 GHz
IEEE 802.11	IEEE 802.11
b	b
g	g
n	n
Receive Sensitivity	270M: -68dBm@10% PER • 130M: -68dBm@10% PER • 108M: -68dBm@10% PER • 54M: -68dBm@10% PER • 11M: -85dBm@8% PER • 6M: -88dBm@10% PER • 1M: -90dBm@8% PER

Security

VPN Pass Through/Multi-Sessions	PPTP, L2TP, IPSec (ESP Head)
Security	Parental Control, Local Management Control, Host List, Access • Schedule, Rule Management
Firewall Filtering	DoS, SPI Firewall • IP Address Filter/MAC Address Filter/Domain Filter • IP and MAC Address Binding

Interfaces/Ports

Number of WAN Ports	1 port(s)
WAN Port Connector	RJ-45
WAN Port Speed	10/100 Mbps
Number of LAN Ports	4 port(s)
LAN Port Connector	RJ-45
LAN Port Speed	10/100/1000 Mbps

Compliance

Standards

CE, FCC, RoHS, Wi-Fi

System

Management

Access Control • Local Management • Remote Management

System Requirements

Operating Systems Supported

Microsoft Windows 8/7/Vista/XP/2000/NT/98SE, MAC OS, NetWare, UNIX or Linux

Electrical

DC Input Voltage	9.0 V DC
Power Adaptor Type	External
AC Input Current	0.5 Amps

Environmental

Operating Humidity	10 to 90 %
Operating Temperature	0 to 40 °C

Physical

Form Factor	Wireless Router
Case Colour	Black
In The Box	450Mbps Wireless N Router TL-WR940N V4.0 • Power Adapter • RJ-45 Ethernet cable • Quick Installation Guide
Width	23.0 cm
Depth	14.4 cm
Height	3.5 cm

Warranty

Three years.
