TP-LINK Gigabit Smart Switch TL-SG2210P is equipped with 8 gigabit RJ45 ports and 2 SFP slots, all RJ45 Ports support the PoE standard with total PoE power budget of 53W and useful PoE power management features. The switch provides high performance, enterprise-level QoS, useful security strategies and rich layer 2 management features. TP-LINK's Gigabit Smart Switch TL-SG2210P is especially designed for the small and medium business networks that require efficient network management. TL-SG2210P comes with a comprehensive set of features, such as Link Aggregation Group, 802.1Q VLAN, Access Control Lists (ACL), Quality of Service(QoS L2 to L4), Storm Control and IGMP Snooping to provide a small or medium-sized business with a network that is geared for growth while ensuring performance and reliability. What's more, its easy-to-use web management interface means faster setup and configuration with less downtime, providing the ideal solution for your business network. The TL-SG2210P supports 8 ports of IEEE 802.3af-compliant PoE and has a total power supply of 53W to power any 802.3af compliant power device. It's an efficient and cost-effective choice to work with wireless access points, surveillance cameras, IP phones and other PoE supported devices, while getting rid of cables or power lines running around. Compact and flexible, the TL-SG2210P is ideal to flexibly use PoE to deploy wireless access points or IP-based network surveillance cameras for projects or small business networks. To integrate voice, data and video service on one network, the switch applies rich QoS policies. Administrator can designate the priority of the traffic based on a variety of means including Port Priority, 802.1P Priority and DSCP Priority, to ensure that voice and video are always clear, smooth and jitter free.In conjunction with the Voice VLAN the switch supports, the voice applications will operate with much smoother performance.
TP-Link TL-SG2210P 8-Port Gigabit PoE Switch
Routing
| Layer 2 Services | IGMP Snooping V1/V2/V3 • 802.3ad LACP (Up to 6 aggregation groups, containing 4 ports per group) • Spanning Tree STP/RSTP/MSTP • BPDU Filtering/Guard • TC/Root Protect • Loop back detection • 802.3x Flow Control • LLDP(LLDP-MED) |
Performance
| Backplane | 20 Gbps |
| MAC Addresses | 8,000 |
| Network Latency | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) • 100BASE-FX:MMF,SMF • 1000BASE-X: MMF, SMF |
| Packet Forwarding Rate | 14.9m pps |
| Port Bandwidth | 10/100/1000 Mbps |
Interfaces/Ports
| Number of Fixed Ports | 8 port(s) |
| Fixed Port Connector | RJ-45 |
| Fixed Port Speed | 10/100/1000 Mbps |
| Fixed Ports/Connectors | Auto-MDI/MDIX |
| Number of Slots | 2 slot(s) |
| Slot Type | SFP |
Wireless
| VLANs | Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs) |
Compliance
| Standards Compliance | IEEE 802.3i, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ad, IEE 802.3af, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p |
| Safety | CE, FCC, RoHS |
System
| Management Capabilities | Web-based GUI and CLI management • SNMP v1/v2c/v3, compatible with public MIBs and • TP-Link private MIBs • RMON (1, 2, 3, 9 groups) • CPU Monitoring • Port Mirroring • Time Setting: SNTP • Firmware Upgrade: TFTP & Web • System Diagnose: VCT • SYSLOG & Public MIBS |
| Security | SSH v1/v2 • SSL v2/v3/TLSv1 • Port Security • Broadcast/Multicast/Unknown unicast Storm Control |
Warranty
| Warranty | 5 Years. |
System Requirements
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8, MAC OS, NetWare, UNIX or Linux |
Electrical
| AC Voltage Range | 100 to 240 V AC |
| Power Consumption | 63.4 W |
| Electrical Frequency | 50 to 60 Hz |
| Power Adaptor Type | AC |
Environmental
| Operating Temperature | 0 to 40 °C |
| Operating Humidity | 10 to 90 % |
Physical
| Form Factor | Network Switch |
| Case Colour | Black |
| In The Box | TL-SG2210P • Power Adapter • Quick Installation Guide • Resource CD • Rubber Feet |
| Width | 20.9 cm |
| Depth | 12.6 cm |
| Height | 2.6 cm |
Key Features
| PoE Supported | Yes |
| Main Colour | Black |
| Switch Type | Managed |
| Switch Form Factor | Desktop |
| LAN Port(s) Speed | 10/100/1000 |
| Number of LAN Port(s) | 8 |
| Number of PoE Ports | 8 |
Item Details
| Manufacturer | TP-Link |
| Manufacturer Code | TL-SG2210P |
| EAN | 6935364022020 |
| UPC | 845973022013 |
| Condition | New |
